The difference between plate chain lifting bucket and ordinary lifting bucket

There are significant differences between the plate chain lifting bucket and the ordinary lifting bucket in terms of structure, applicable materials, performance characteristics, and maintenance costs, as follows:

1、 Structural differences

Plate chain lifting bucket

Traction components: Made of high-quality alloy steel high-strength plate chains, consisting of single or double row chains, with a sturdy structure and light weight.

Hopper connection: The hopper is directly fixed by a plate chain, and the connection strength between the chain and the hopper is high, suitable for high load scenarios.

Drive device: The driving power is 25% -45% of the chain hoist, using a hard toothed reducer for smooth operation.

Ordinary lifting bucket

Loop chain lifting bucket: The traction component is a circular chain with a simple structure but a large self weight. The chain is firmly connected to the hopper, but the hinged joint is prone to wear.

Tape lifting bucket: The traction component is made of rubber tape or steel wire rope tape, with a simple structure and light weight, but poor high temperature resistance and wear resistance.
